60W with 2 Pair PoE 10gbe poe injector use for IoT application and smart home
Product Review:
midspan PoE injector works with a wide input voltage of 12-55Vdc make it possible for solar application and operates
under -40℃ to +65℃, For planning purposes, the effective distance is 100 meters over Cat5e/Cat6 cables.
Product Specifications:
| Working Environment | midspan PoE injector Operating Temperature: -40℃ to 65℃ |
| Operating Humidity: 20% to 80%, non-condensation |
| Storage Temperature: -40℃ to 85℃ |
| Storage Humidity: 10% to 90%, non-condensation |
| Operating Altitude: up to 5000meters |
| PoE Surge Protection | Protected line: 1,2,3,4,5,6,7,8 |
| Common mode surge protection(10/700us): 6KV |
| Differential mode surge protection (10/700us): 1.5KV |
| Mechanical Characteristics | Size: 144.5mmX 95mmX35.4mm |
| midspan PoE injector Weight: 400g(0.88lb) |
| Safety Approvals | CE, FCC |
Company Introduction:
PROCET(Creative Lianjie Network Technology Co.,Ltd) born in 2000. PROCET mainly R&D on the PoE
(Power over Ethernet) series product, Outdoor PoE, indoor PoE, Lightning&surge protection PoE.-40℃ to +65℃
PoE,usb c power injector, PoE extender and midspan PoE injector. We registered PROCET Technology Co., Ltd
in HONGKONG in 2019.PROCET PoE injector has been widely favored by customers since its development.
Certification:
Shipping and Payment:
| MOQ | 1PC |
| PORT | SHENZHEN |
| PAYMENT TERMS | T/T,WESTERN UNION/OTHER |
| PRODUCING CAPACITY | 500,00 Per/Month POE Module and POE Splitter,10000 Per/Month midspan PoE injector |
| LEADING TIME | SMALL quantities in stock.Large quantities 20-30 days |
| BOX | Industrial fiber PoE injector Carton packaging |
FAQ:
1.What is the maximum power output of the PT-PSE105GW-E-10 midspan PoE injector?
The PT-PSE105GW-E-10 PoE injector can deliver up to 60 watts of power per port.
2.What is the input voltage range supported by the PT-PSE105GW-E-10 midspan PoE injector?
The PT-PSE105GW-E-10 60 watt PoE injector supports an input voltage range of 12-55Vdc.
3.How many PoE ports does the PT-PSE105GW-E-10 midspan PoE injector have?
The PT-PSE105GW-E-10 60 watt PoE injector has 1 PoE port.
4.Is the PT-PSE105GW-E-10 midspan PoE injector compatible with all PoE-enabled devices?
The PT-PSE105GW-E-10 PoE injector is compatible with most PoE-enabled devices.
5.Does the PT-PSE105GW-E-10 midspan PoE injector support PoE+ (802.3at) or only PoE (802.3af)?
The PT-PSE105GW-E-10 PoE injector supports both PoE (802.3af) and PoE+ (802.3at) standards.
6.Does the PT-PSE105GW-E-10 midspan PoE injector provide any protection features?
Yes, the PT-PSE105GW-E-10 midspan PoE injector provides various protection features, including
over-current protection,short-circuit protection, and surge protection.
